5. RC1815/RC1825 Equipment Setup
5-7
5.5 FS-1570/FS-2570
Refer to the Installation Manual, FS-1570 (150W) / FS-2570 (250W)
5.5.1 General
1) Power up the unit and press the [1/RT] key.
2) Press the [3/TEST]. Allow the test to complete and verify all checks are OK.
5.5.2 RT Operation
1) On each band, verify that the antenna automatically tunes when the
[LOG/TUNE] key is pressed.
2) If all tests are OK, proceed on to the next section. If the tune fails, verify the
antenna, grounding system and the coupler connections.
5.5.3 MMSI
1) To set the MMSI, refer to the Dealers Manual, Pg. 4.
5.5.4 Manual 2182 kHz Tuning Preset
1) Press the [1/RT/2182] key for 2 seconds.
2) Press the [LOG/TUNE] key, TUNING: OK will appear when the tuning
is complete.
3) Open the coupler and record the status of the LED’s CR1-CR22.
(Refer to Pgs. 3-1 and 3-2 of the Installation Manual, FS-1570 (150W) /
FS-2570 (250W))
4) Set S1 to Manual. Set switches S4, S5 and S6 to match the LED’s recorded
in step 3.
5) Set S1 to AUTO. The LED’s should stay the same as step 4.
6) Secure the antenna coupler cover.
