DESCRIPTION
RC1840
Interconnect Drawing
Control
Unit
FM-8500
See Notes
FURUNO
Felcom 15
IC-215
FURUNO
IB-581
FURUNO
IC-115
000-146-250
IC-315
Junction Box
Junction
Ant
Keyboard
PP-510
Keyboard
Printer
24 VDC
from
Meter
Box
NMEA
Out
IC-305
AT-5000
D. ANT
Coupler
TX
ANT
Handset
Keyboard
NBDP
24 VDC
from
PR850A
Notes:
1) Local Supplied
Factory Supplied
2) All External Connections Must be Fused.
3) Two FM-8500's supplied with each console,
only one shown for simplification.
24 VDC
from
Meter Box
24 VDC
from
Meter
Box
NMEA
from
IC-315
T/R
ANT
RX
ANT
Handset
000-138-000
FS-5000
Transceiver
RX
ANT
PP-510
Printer
Switch
A
BCOM
Main
Unit
DSC-60
24 VDC
from
Meter
Box
Rem 2
Rem 1
RT
Printer
Printer
NMEA
from
IC-315
Fax-5
Coupler
Long Wire or
Whip Antenna
