iv
SYSTEM CONFIGURATION
PC Monitor
(User supply)
Surface Processor Unit
Winch
Power
source
100-240VAC
1
φ
, 50-60 Hz
Underwater Unit
Catch Sensor (option)
(4 max.)
: Standard supply
: Optional supply
: Local, user supply
Cable Block
UNDERWATER SECTION
SHIPBOARD SECTION
Mouse
Keyboard
System configuration
