VNAV INDICATOR
NOTE: VNAV deviation is only displayed when the G5 is receiving NMEA
RS-232 data from a portable GPS.
The magenta chevron (VNAV Indicator) to the left of the altimeter on the Vertical
Deviation Scale displays the VNAV profile.
VNAV Indicator
VNAV
Indicator
2.8.3 COURSE SELECTION
When the G5 is receiving VOR or LOC data, a Course menu option is displayed.
Setting the course for a VOR or localizer:
1) From the PFD Page, press the Knob to display the Menu.
2) Select Course and use the Knob to adjust the course.
VLOC Course on PFD Page
