1.2 INSTALLATION PREPARATION
This section provides electrical and mechanical information needed for planning the
physical layout of the G5 installation. Use the information in Section 1.2 to become
familiar with all aspects of the installation before actually beginning the physical
installation of any equipment into the aircraft. Garmin recommends that the installer
become familiar with all sections of this document before beginning the installation.
In general terms, the below steps are recommended to be followed in order.
1) Inventory of all needed parts
2) Planning/layout of the installation
3) Installation of LRUs, antennas, and sensors
4) Construction of wiring harness, cables, and connectors
5) Software installation/configuration
6) Post-installation checkout procedure and calibration
1.2.1 ELECTRICAL CONSIDERATIONS
This section presents information required for planning the electrical layout of the
G5 installation.
CAUTION: To avoid damage to the G5 and other LRUs, take precautions
to prevent Electro-Static Discharge (ESD) when handling connectors and
associated wiring. ESD damage can be prevented by touching an object that
is of the same electrical potential as the LRU before handling the LRU itself.
