DISENGAGING THE AUTOPILOT
The Autopilot is manually disengaged by pressing the autopilot disconnect button
on the control stick or yoke or by pressing the AP Key on the GMC 305/307. Manual
disengagement is indicated by a five-second flashing yellow ‘AP’ annunciation. Cancel
the aural alert by pressing and releasing the AP/CWS Button again.
Automatic disengagement is indicated by a flashing red ‘AP’ annunciation. Automatic
disengagement occurs due to:
•
System failure
•
Invalid sensor data
•
Inability to compute default autopilot modes
•
Detection of a GDU display on the CAN network (when installed as part
of a G3X/G3X Touch system).
diSenGaGinG the autoPiLot when a maLfunCtion iS SuSPeCted
If an autopilot failure or trim failure is suspected to have occurred, perform the
following steps:
1)
Firmly grasp the control wheel.
2)
Press and hold the AP DISC Switch. The autopilot will disconnect and power
is removed from the trim motor. Power is also removed from all primary
servo motors and engaged solenoids. Note the visual alerting indicating
autopilot disconnect.
3)
Retrim the aircraft as needed. Substantial trim adjustment may be needed.
4)
Pull the appropriate circuit breaker(s) to electrically isolate the servo and
solenoid components.
5)
Release the AP DISC Switch.
