ACTIVATING THE FLIGHT DIRECTOR
An initial press of a key listed in the table below (when the flight director is not
active) activates the flight director in the listed modes. The flight director may be
turned off and the Command Bars removed from the display by pressing the FD Key
again. The FD Key is disabled when the autopilot is engaged.
Control Pressed
Modes Selected
Lateral Vertical
FD Key Roll Hold (default) ROL Pitch Hold (default) PIT
AP Key Roll Hold (default) ROL Pitch Hold (default) PIT
TO/GA Button
Takeoff (on ground)Go
Around (in air)
TO
GA
Takeoff (on ground)
Go Around (in air)
TO
GA
ALT Key Roll Hold (default) ROL Altitude Hold ALT
VS Key Roll Hold (default) ROL Vertical Speed VS
VNV Key Roll Hold (default) ROL Vertical Navigation* VNV
IAS Key Roll Hold (default) ROL Indicated Airspeed IAS
APR Key Approach** GPS Pitch Hold (default) PIT
NAV Key Navigation** GPS Pitch Hold (default) PIT
HDG Key Heading Select HDG*** Pitch Hold (default) PIT
LVL Key Level Hold LVL Level Hold LVL
*Must be receiving VNAV data from a portable GPS via RS-232 before VNV Key press activates flight
director.
**The selected navigation receiver must have an active GPS course before NAV or APR Key press
activates flight director.
*** HDG mode is only available when magnetic heading data is being received from an ADAHRS unit,
when the G5 is installed as a backup unit in a G3X/G3X Touch system.
