Vertical
Mode
Description Control Annunciation
Reference
Change
Increment
Vertical
Navigation
Captures and tracks descent
legs of an active vertical profile
VNV Key
(GMC
305/307)
VNV***
Glidepath
Captures and tracks the SBAS
glidepath on approach
APR Key
(GMC
305/307)
GP
Takeoff
Commands a constant pitch
angle and wings level on
ground in preparation for
takeoff
GA
Button
TO**
Go Around
Commands a constant pitch
angle and wings level in the air
GA**
* ALTS armed automatically when PIT, VS, IAS, or GA active, and under VNAV when Selected Altitude
is to be captured instead of VNV Target Altitude
** TO and GA modes are only displayed when the G5 is configured as a backup unit in a G3X/G3X
Touch system.
*** VNV mode (only available as part of a standalone G5 installation when receiving NMEA RS-232
data from a portable GPS).
Flight Director Vertical Modes
