ROLL HOLD MODE (ROL)
NOTE: If Roll Hold Mode is activated as a result of a mode reversion, the
flight director rolls the wings level.
When the flight director is activated or switched, Roll Hold Mode is selected by
default. This mode is annunciated as ‘ROL’ in the Autopilot Status Box. The current
aircraft bank angle is held, subject to the bank angle condition.
Roll Hold Mode Annunciation
Bank Angle Flight Director Response
< 6° Rolls wings level
6 to 20° Maintains current aircraft roll attitude
>20° Limits bank to 20°
Roll Hold Mode Responses
ChanGinG the roLL referenCe
When operating in Roll Hold Mode, the roll reference can be adjusted in the following
ways:
•
Hold the CWS Button (if equipped), establish the desired bank angle,
then release the CWS Button.
