TRACK MODE (TRK)
Track Mode is activated by pressing the
HDG Key
. Track Mode acquires and
maintains the Selected Ground Track. The Selected Ground Track is displayed as a
magenta bug on the HSI and in the box on the bottom right of the HSI.
Changing the selected ground track:
1)
Press the Knob to display the Menu.
2)
Select Track and use the Knob to change the Selected Ground Track.
Or:
Rotate the HDG Knob on the GMC.
Activating track mode:
Press the HDG Key on the GMC.
Holding the CWS Button (if equipped) and hand-flying the aircraft does not
change the Selected Ground Track. The autopilot guides the aircraft back to
the Selected Ground Track upon release of the CWS Button.
Turns are commanded in the same direction as Selected Ground Track Bug
movement, even if the Bug is turned more than 180˚ from the present heading
(e.g., a 270˚ turn to the right). However, Selected Ground Track changes of
more than 330˚ at a time result in turn reversals.
Track Mode Annunciation
