zūmo 500/550 Owner’s Manual 5
Managing Files on Your zūMo
ManaGinG fileS on
Your zūmo
You can load les to the internal memory
or an optional SD card.
NOTE: The zūmo is not
compatible with Windows
®
95,
Windows 98, or Windows Me
operating systems. This is a
common limitation of most USB
Mass Storage Devices.
Supported File Types
MP3 music les
M3U playlist les
JPEG and JPG image les for splash
screen or picture viewer
GPI custom POI les from Garmin’s
POI Loader
GPX waypoint les and maps from
MapSource
NOTE: The zūmo does not
support iTunes
®
M4A/M4P les.
Step 1: Insert an SD Card
(Optional)
To insert or remove the card, press it in
until it clicks.
SD card
slot
Mn
-USB port for AC
power, USB Mass Storage
mode, and updatng
software
Step 2: Connect the USBUSB
Cable
1. Plug the small end of the USB cable
into the mini-USB port.
2. Connect the larger end of the USB
cable to an available USB port on
your computer.
