GE 45255 User Manual

3
Congratulations on your purchase of the GE Wireless Color
Digital Home Monitoring Kit! Please review these instructions
carefully and retain them for your future reference.
FEATURES
 CAMERA
• 2.4GHz digital wireless technology—private and secure
monitoring with interference-free picture and sound
• Built-in motion and/or sound detection
• Built-in night vision (black & white, up to 20ft visibility)
• Built-in microphone for broadcasting audio to monitor
automatically
• Built-in night light (manually activated on camera or
remotely activated on monitor)
• (4) Musical lullabies (remotely activated on monitor)
• Tabletop or wall mount options
• Portable operation using (4) AA batteries or optional
rechargeable battery pack (sold separately at www.
jascoproducts.com)
night light
(manual or
remote control)
speaker
(lullabies &
audio from
monitor)
infrared LEDs
(night vision)
4.9mm lens
IR light
sensor
temperature
sensor
microphone
battery
compartment
(4 -AA)
wall mount slots
volume control
sensitivity
control
power
switch
power
LED
(fl ashes
when
power is
low)
pairing
control
AC power

GE 45255 Specifications

General Specifications

RF Frequency	2.4~2.48 GHz
Transmit Power	16 dBm
RF Range	450 ft Unobstructed Line of Sight

Operating Environment

Operational Temperature	-20~55C @ 5~85% RH non-condensing, -4~131F @ 5~85% RH non-condensing
Storage Temperature	-30~60C @ 5~85% RH non-condensing, -22~140F @ 5~85% RH non-condensing

Power

AC/DC Adapter Input	120 VAC
AC/DC Adapter Output	5 V @ 1 A
Current Consumption	540 mA

Camera Specifications

Imaging Sensor	¼” CMOS
Lens Type	4.9 mm F2.8
Minimum Illumination	0 Lux with IR Illumination
System Resolution	QVGA (320X240)-Monitor
Imager Resolution	VGA (640 x 480)
View Angle	45º

Battery

Battery Type	4 AA Alkaline
Battery Life	Up to 4 hours, Up to 5 hours

Monitor Specifications

LCD Size	3.5” Diagonal
System Resolution	QVGA (320X240)-Monitor
Current Consumption	850 mA
Memory Card	Micro SD (32GB max)
Output Port	USB 2.0
