GE AF-300 P11 User Manual

4-5
Data subject to change without notice 7/07. © 2007 GE Drives
4.3.3 Switching to LED Digital Monitor
During normal operation, press
FUNC
DATA
to switch to LED monitor display. When monitored data is switched, the LED
monitor contents are displayed. When power is turned on, the monitor contents set by the function (E43) are displayed
on the LED.
4.3.4 Program Menu Screen
The Program Menu screen is shown below. Only four items can be displayed simultaneously. Move the cursor
with
or to select an item, then press
FUNC
DATA
to display the next screen.
4.3.5 Setting Function Data
On the Program Menu screen, select 1. Data Setting. The Function Select screen appears with function codes and
names on it. Select the desired function.
60.00 60.00
60.00
60.00
RUN
PRG PRG MENU
F/D LED SHIFT
1. DATA SETTING
2. DATA CHECK
3. OPR MNTR
4. I/O CHECK
F00 DATA PRTC
F01 FREQ COM 1
F02 OPR METHOD
F03 MAX Hz-1
F01 FREQ COM 1
0
0-11
Function Code Function Name
Data Setting Range
Data
1. DATA SETTING
2. DATA CHECK
3. OPR MNTR
4. I/O CHECK
5. MAINTENANCE
6. LOAD FCTR
7. ALM INF
8. ALM CAUSE
9. DATA COPY
DISPLAY
4. I/O CHECK
5. MAINTENANCE
6. LOAD FCTR
7. ALM INF
When running Unit Remarks
(E44 = 0) (E44 = 1) (E44 = 0.1)
0 Setting frequency Hz
1 Setting frequency
2 Setting frequency
3 Output current A
4 Output voltage V
(specified value)
5 Synchronous r/min.
speed setting
value
6 Line speed m/min.
setting value
7 Load rotation r/min.
speed setting
value
8 Torque calculation % ± indication
value
9 Power kW
consumption
10 PID setting value —
11 PID remote —
setting value
12 PID feedback value —
E43
PID remote setting value
PID feedback value
For 4 digits or more, the lasr
digits are cut, with x10, x100
marked on the indicator.
Displayed only when PID is
effective in PID operation
selection.
Power consumption
PID setting value
Load rotation speed
Torque calculation value
Line speed
Output current
Output voltage (specified value)
Synchronous speed
When stopping
Output frequency 1 (before slip compensation)
Output frquency 2 (after slip compensation)
Setting frequency
PRG
FUNC
DATA
FUNC
DATA
