GE AF-70 LP User Manual

AF-70 LP
Quick Start Up
Quick Start Process
1
7

6
1.4. QuickStartOverview
QuickStart–IP20&IP66NonSwitched

•
ConnectaStart/Stopswitchbetweencontrolterminals1&2
o ClosetheSwitchtoStart
o OpentoStop
• Connectapotentiometer(5k–10kΩ)betweenterminals5,6and7asshown
o AdjustthepotentiometertovarythespeedfromF-02(0Hzdefault)toF-01(50/60Hz
default)
QuickStart–IP66Switched

Switchthemainspowerontotheunitusingthebuiltinisolatorswitchonthefrontpanel.
TheOFF/REV/FWDwillenablethe
outputandcontrolthedirectionof
rotationofthemotor.







Thepotentiometerwillcontrolthemotorshaftrotationalspeed.
 
