EX2100 User’s Guide GEH-6632 Chapter 3 Printed Wiring Boards Overview
•
••
•
3-11
Related Board Publications
For a more detailed description of each board's circuitry and application data, refer to
the following documents:
• GEI-100460 IS200EBKP Exciter Backplane
• GEI-100267 IS200DSPX Digital Signal Processor Board
• GEI-100434 IS215ACLAH1 Application Control Layer Board
• GEI-100454 IS200EISB Exciter ISBus board
• GEI-100453 IS200EMIO Exciter Main I/O board
• GEI-100456 IS200ESEL Exciter Selector board
• GEI-100459 IS200EPCT Exciter PT/CT board
• GEI-100457 IS200ECTB Exciter Contact Terminal Board
• GEI-100458 IS200EXTB Exciter Terminal Board
• GEI-100464 IS200EDCF Exciter DC Feedback board
• GEI-100465 IS200EACF Exciter AC Feedback board
• GEI-100461 IS200EGPA Exciter Gate Pulse Amplifier board
• GEI-100466 IS200EDEX Exciter De-Excitation board
• GEI-100467 IS200EGDM Exciter Ground Detector Module
• GEI-100463 IS200EPBP Exciter Power Backplane
• GEI-100462 IS200EPSM Exciter Power Supply Module
