GE Fuji Electric AF-300ES User Manual

4-13
Dynamic Braking
Braking Torque CT Applications VT Applications Dynamic
Model No. Built in Optional Duty Brake Duty Brake Braking Qty DB Resistor Qty Max Total
Resistor Resistor Factor Time Factor Time Module Reqd Model Reqd KW Ohms
230 VAC, 3 Phase, 60 Hz Input Power
6KE$223F50X1A1 100% 150% 22 45 SEC N/A N/A BUILT-IN N/A 6KE$32DBR001 1 0.2 100.0
6KE$223001X1A1 100% 150% 18 45 SEC N/A N/A BUILT-IN N/A 6KE$32DBR001 1 0.2 100.0
6KE$223002X1A1 100% 150% 10 45 SEC N/A N/A BUILT-IN N/A 6KE$32DBR003 1 0.4 40.0
6KE$223003X1A1 100% 150% 7 30 SEC N/A N/A BUILT-IN N/A 6KE$32DBR003 1 0.4 40.0
6KE$223005X1A1 100% 150% 5 20 SEC N/A N/A BUILT-IN N/A 6KE$32DBR005 1 0.4 40.0
6KE$223007X1A1 100% 150% 5 20 SEC 3.5 15 SEC BUILT-IN N/A 6KE$32DBR007 1 0.8 20.0
6KE$223010X1A1 100% 150% 5 10 SEC 3.5 7 SEC BUILT-IN N/A 6KE$32DBR010 1 0.9 15.0
6KE$223015X1A1 20% 150% 5 10 SEC 3.5 7 SEC 6KE$32DBU025 1 6KE$32DBR015 1 1.4 12.0
6KE$223020X1A1 20% 150% 5 10 SEC 4 8 SEC 6KE$32DBU025 1 6KE$32DBR020 1 1.4 12.0
6KE$223025X1A1 20% 150% 5 10 SEC 4 8 SEC 6KE$32DBU025 1 6KE$32DBR025 1 1.8 10.0
6KE$223030X1A1 20% 150% 5 8 SEC 6KE$32DBU030 1 6KE$32DBR030 1 1.8 8.6
460 VAC, 3 Phase, 60 Hz Input Power
6KE$243001X1A1, B1 100% 150% 10 45 SEC N/A N/A BUILT-IN N/A 6KE$34DBR001 1 0.2 160.0
6KE$243002X1A1, B1 100% 150% 10 45 SEC N/A N/A BUILT-IN N/A 6KE$34DBR003 1 0.4 160.0
6KE$243003X1A1, B1 100% 150% 7 30 SEC N/A N/A BUILT-IN N/A 6KE$34DBR003 1 0.4 160.0
6KE$243005X1A1, B1 100% 150% 5 20 SEC N/A N/A BUILT-IN N/A 6KE$34DBR005 1 0.4 160.0
6KE$243007X1A1, B1 100% 150% 5 20 SEC 3.5 15 SEC BUILT-IN N/A 6KE$34DBR007 1 0.8 80.0
6KE$243010X1A1, B1 100% 150% 5 10 SEC 3.5 7 SEC BUILT-IN N/A 6KE$34DBR010 1 0.9 60.0
6KE$243015X1A1, B1 20% 150% 5 10 SEC 3.5 7 SEC 6KE$34DBU030 1 6KE$34DBR015 1 1.4 48.0
6KE$243020X1A1, B1 20% 150% 5 10 SEC 4 8 SEC 6KE$34DBU030 1 6KE$34DBR020 1 1.4 48.0
6KE$243025X1A1, B1 20% 150% 5 10 SEC 4 8 SEC 6KE$34DBU030 1 6KE$34DBR025 1 1.8 40.0
6KE$243030X1A1, B1 20% 150% 5 8 SEC N/A N/A 6KE$34DBU030 1 6KE$34DBR030 1 1.8 34.4
6KE$243035X1A1 10% 100% N/A N/A 8 8 SEC 6KE$34DBU050 1 6KE$34DBR040 1 3.6
6KE$243040X1A1 10% 100% 10 10 SEC 8 8 SEC 6KE$34DBU050 1 6KE$34DBR040 1 3.6 15.0
6KE$243050X1A1 10% 100% 10 10 SEC 8 8 SEC 6KE$34DBU050 1 6KE$34DBR050 1 4.8 12.0
6KE$243060X1A1 10% 100% 10 10 SEC 8 8 SEC 6KE$34DBU075 1 6KE$34DBR060 1 6 10.0
6KE$243075X1A1 10% 100% 10 10 SEC 7 7 SEC 6KE$34DBU075 1 6KE$34DBR075 1 7.2 7.5
6KE$243100X1A1 10% 100% 10 10 SEC 8 8 SEC 6KE$34DBU150 1 6KE$34DBR050 2 9.6 6.0
6KE$243125X1A1 10% 100% 10 10 SEC 8 8 SEC 6KE$34DBU150 1 6KE$34DBR060 2 12 5.0
6KE$243150X1A1 10% 100% 10 10 SEC 8 8 SEC 6KE$34DBU175 1 6KE$34DBR060 3 18 3.75
6KE$243200X1A1 10% 100% 10 10 SEC N/A N/A 6KE$34DBU150 2 6KE$34DBR050 4 19.2 3.0
6KE$243250X1A1 10% 100% 10 10 SEC N/A N/A 6KE$34DBU150 2 6KE$34DBR060 4 24 2.5
6KE$243300X1A1 10% 100% 10 10 SEC N/A N/A 6KE$34DBU150 2 6KE$34DBR075 4 28.8 1.88
4-008
Note: Duty Factor is the % of calculated total cycle time NOT to exceed the listed brake time for the total cycle.
Total Cycle Time = ( Brake time Duty Factor)* 100
