2-1
Section 2: Description, Component Identication and Specifications
The AF-300E$ drive is available in ratings of 0.5 to 30 Hp
200-230 VAC, 1 to 300 Hp (350Hp variable torque) 380-460
VAC. The AF-300E$ drive incorporates multiple control al-
gorithms with either the traditional PWM Scalar power con-
trol or a selectable torque vector algorithm with a self tuning
drive/motor function that is used in high performance opera-
tion. The AF-300E$ Drives are housed in a NEMA 1 type
enclosure for either open or panel mounting and all Inverters
are furnished with a detachable wiring lead-in plate to allow
ease of accessing control and power wiring.
Drive operation and Function Code setting is performed from
the “Keypad Panel” that also features a Digital Monitor, LCD
Graphic Display and 8 dual function keys. The 8 dual func-
tion keys are used for drive programming and operation as
well as selection of drive local/remote operation.
General data and specification for each drive are listed on
the nameplate attached to the drive. Refer to TABLE 1 for
complete AF-300E$ drive specification listing.
All models are UL Listed and CSA Approved*
(Nameplate shown larger than actual size.)
Figure 2-1. NAMEPLATE DATA IDENTIFICATION
INSPECTION PROCEDURES UPON DELIVERY
Upon receipt of your drive, inspect the equipment for the
following items:
1. Check the nameplate to insure that the specifications
correspond to those ordered.
2. Inspect the unit for any damage that may have occurred
during shipment.
If shipping damage is found or the wrong Inverter is
received, contact the distributor from which this
equipment was purchased.
* CE Mark for three-phase (3ø), 415 VAC, 1 to 30 Hp only.
GE Fuji Drives America Made in Mexico
AF-300E$
TM
MODEL NO.
SERIAL NO.
INPUT:
VOLTS
AMPS
FREQ (HZ)
PHASE (S)
INSTRUCTION
BOOK GEI-100211
VARIABLE
TQ OUTPUT:
CONSTANT
TQ OUTPUT:
VOLTS
FREQ RANGE (HZ)
HP
AMPS CONT.
PHASE
ROTATION
MAX 60 SEC. AMPS
