2-3
Environmental Conditions
Enclosures NEMA 1 Standard
Installation Location Suitable for indoor mounting only, less than 1000 meters (3300 feet) elevation, not in
contact with corrosive gas, oil mist, dust, and out of direct sunlight.
Stored Temperature -20° to +65°C (-4° to + 149°F)
Ambient Temperature -10 to +50
o
C (+14 to +122
o
F) (remove ventilation covers if temperature is over +40
o
C
[+104
o
F] up to 30 Hp; 40 Hp and above not required.)
Humidity 20% to 90% relative humidity (non-condensing).
Vibration 0.6G or less.
Cooling Method 1/2 to 1 Hp – Convection
2 Hp and greater – Forced air
Output
Rated Output Voltage 3-Phase, 3-Wire Type, 80-240 VAC or 320-480 VAC
(Can not exceed power supply voltage).
Frequency Range 0 - 400 Hertz (0.2 to 60 Hz start frequency; 0.2 to 120 Hz base frequency).
Above 120 Hz, contact Company for approval of application.
Overload Current Rating – 30 Hp and lower
150% for 1 minute duration (inverse time characteristic)
200% for 0.5 seconds
– 40 Hp and greater
150% for 1 minute duration (inverse time characteristic) 180% for 0.5 seconds
Power Supply
Rated Input AC Voltage – 200 to 230 VAC 50/60 Hz, 3 phase (1/2 to 30 Hp)
– 380 to 400 VAC 50 Hz, 3 phase (1 to 300 Hp) CT
– 380 to 480 VAC 60 Hz, 3 phase (1 to 300 Hp) CT
– 460-480 VAC, 60 Hz, 3 phase, 40 Hp and above, variable torque applications only
Voltage - +10%, -15%; Voltage Unbalance - Within 3%; Frequency - +/-5% Units are
dual rated Constant Torque/Variable Torque. Drive looks for a similar Volts/Hz ratio).
Control System Sinusoidal PWM Control (or with torque-vector control.)
Momentary Voltage Dip When the input voltage dips below 165 VAC (230V System), 310 VAC (460V system) or
400 VAC (575V System), the Drive can operate for 15 ms with 85% full load applied.
Starting Torque 150% (when torque vector control is active.)
Carrier Frequency – 2 to 15 KHz (1/2 to 30 Hp) 230 & 460 VAC
– 2 to 10 KHz (40 to 75 Hp) – 2 to 6 KHz (100 Hp and greater)
Table 1: AF-300E$ – Standard Specifications
