L CD
GRAPHIC FACTORY
FUNCTION DISPLAY SETTING DESCRIPTION SETTING
6-32
* 79 BRIGHTNESS LCD GRAPHIC DISPLAY MONITOR BRIGHTNESS 5
1 TO 10
Bright (1) to Dark (10)
* 80 81-94 FUNCTION CODE BLOCK DISPLAY 0
This setting determines whether or not
Function Codes 81 through 94 will be
displayed and available for adjustment.
0:
Function Codes 81 through 94 NOT displayed.
1:
Function Codes 81 through 94 displayed.
* 81 MTR SOUND MOTOR SOUND 0
Allows the selection of the carrier freq-
uency that determines the quality of the
sound produced by the motor.
0 TO 10
Low carrier (0) to High carrier (10)
82 RESTART t RESTART TIME 0.1S
Time from frequency output reaching zero to (30HP and less)
frequency output restarting. 0.5S
See Function Code 10 (Restart) (40HP and greater)
0.0 TO 5.0
Time in seconds
83 FALL RATE RATE OF FALL 10.00
This Function Code sets the deceleration rate
for the motor during lead-in when Function
Code 10 (RESTART) is active and a momentary
power failure occurs.
0:
Deceleration occurs for the set decel time.
1 TO 100
Deceleration occurs for the value set in
Hz per second.
* 84 AUTO-RESET
AUTOMATIC RESET TIMES 0
Selects the number of times the drive
will attempt to reset after a fault condition.
0 TO 7
Reset after overcurrent, overvoltage, low
voltage, overheating and overload faults.
WARNING: Personal safety must be considered when activating
this function.
