a--
AF-300
MXO-$AVER
Drive Components
1.
Unit Cover
2. Terminal Cover
3
Keypad Panel
4. Heat Sink
5. Mounting Screw Holes
6. Terminal Cover Screws
Figure 2-3. TYPICAL DRIVE
COl\liPONENTS
Step 1:
Remove Terminal
Cover screw.
Step 2:
Unlock tabs at the locations
indicated by the arrows to
remove the terminal cover.
Drive
Charge Lamp
Figure 2-4. INSTALLING AND REMOVING TERMINAL COVER
2-3
