Chapter 3: Configuration and commissioning
30 Kilsen KFP-CF Series Installation Manual
Default delays
The default extended fire routing delay for each operating mode is shown below.
Operating mode Default delay in minutes
EN 54-2 Scandinavia 03
NEN 2535 03
EN 54-2
EN 54-2 Evacuation
BS 5839-1
NBN S21-100
This feature is not available in these operating modes.
Delay logic
Fire routing and extended fire routing delays elapse concurrently when a fire alarm
event is reported.
In NEN 2535 operating mode, the extended fire routing delay becomes the active
delay when sounders are stopped (by pressing the Sounder Start/Stop button) and
remain stopped when the standard fire routing delay time has elapsed.
In EN 54-2 Scandinavia operating mode, the extended fire routing delay becomes the
active delay when an extended fire routing delay switch (connected to INPUT1) is
activated while the standard fire routing delay elapses.
Extended delay application logic
Depending on your fire alarm system configuration and the alarm activation device, a
configured delay may be overridden.
Extended fire routing delays will only be applied when:
• Both fire routing and extended fire routing delays are configured and enabled.
• The operating mode requirements for the extended delay activation are true (see
the previous topic for differences in NEN 2535 and EN 54-2 logic).
• The zone delay configuration is set to allow delays in the zone reporting the fire
alarm. (This is the default configuration.)
Add an expansion module
For information on how to add an expansion module to the fire system and how to
configure the module, see “Expansion module configuration” on page 39.
