Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Chapter 5 Components and Functions (Theory) 5-3
5-2-2 General Information
• LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e is an ultrasound imaging scanner.
• The system can be used for:
- 2D Black and White imaging
- 2D Color Flow
- M-Mode Black and White imaging
- Doppler
- A number of combinations of the above
• LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e is a digital beam forming system that can handle up to 128
elements linear probes.
• Signal flow from the Probe Connector Panel to the Front End, to the Mid Processors and Back End
Processor and finally to the LCD and peripherals.
• System configuration is stored on a hard disk drive and all necessary software is loaded from the
hard disk drive on power up.
