Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Chapter 7 Diagnostics/Troubleshooting 7-19
7-7-2 Insite II Configuration
6.) Enter global service user interface, and log in as GE Service. See section 7-5-1 on page 9.
7.) To use Pilot Server, on Configuration
page, choose Questra Agent Configuration in left column.
Select Advanced Configuration
, then choose “Others” as server type, and manually input pilot
address, and click SAVE
.
NOTE: If system is within GE network, choose Development
as server type, and do not need step 9.) enter
Proxy Server address.
Figure 7-18 Advanced_Configuration page (out of GE network)
Figure 7-19 Advanced_Configuration page (within GE network)
