Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
7-16 Section 7-7 - Network and Insite II Configuration
7-7-1-1 Wire-LAN Network (cont’d)
NOTE: If user want to setup static IP address, uncheck Enable DHCP
option, input static address in
IP-Address
box, Subnet Mask and Default Gateway box. In Network Speed box, choose the
proper speed available.
3.) Click Save
, in popped-up dialog choose Ok.
4.) After reboot, the network icon at the left bottom of screen turns green.
Figure 7-10 Input static address
Figure 7-11 Save and reboot inquiry dialog
Figure 7-12 Network icon
