GE MLJ1000 User Manual

GEK - 105560
18
4. TECHNICAL CHARACTERISTICS
4.1 MODEL LIST
Here is the information required to completely define the MLJ models. (See chart below):
MLJ 100
_
A010
_
00
_
Communications Auxiliary and inputs voltage Case
0 - No communications F - 24/ 48 Vdc C - In individual case
5 - RS-485 H - 110/ 250 Vdc S - In MID system
6 - RS-485, 232, plastic optic fiber
7 - RS-485, 232, glass optic fiber
4.2 TECHNICAL CHARACTERISTICS
•
FREQUENCY
50 and 60 Hz, programmable by user.
•
NOMINAL VOLTAGE
63 to 220 Vac.
•
AUXILIARY POWER
24 - 28 Vdc
±
20%
110 - 250 Vdc
±
20%
•
MAXIMUM VOLTAGE ALLOWABLE
Continuous: 440 Vac.
•
TEMPERATURE RANGES
Operating: -25ºC to +55ºC
Storage: -40ºC to +65ºC
Comply with IEC standard 255-6 (for the -25º to +55ºC interval) and ANSI C37.90 (specifying the -
25º to +55ºC interval).
•
AMBIENT HUMIDITY
Up to 95% without condensation.
•
CLOSURE ENABLE CONTACTS
Break capacity: 4000 VA
Maximum continuous voltage: 300 Vdc
Maximum alternating voltage: 440 Vac
Carry continuously: 16 A
Make and carry: 30 A
