GEK - 105560
28
6.3 CALIBRATION SEQUENCE
Under normal conditions, the relay will not need to be calibrated.
The calibration of this protection is done in the factory in a controlled environment with high precision
equipment. Therefore, not only is it unnecessary to recalibrate the relay, but also not recommended.
The relay has a single gain calibration by means of a potentiometer (see figure 6).
