6.4 SUMMARY OF SETTINGS
Following, is a table containing a summary of all the settings of the MLJ relay. In addition to the
description and the setting code, the allowable values, step and default value (the value the relay
comes with from the factory) are indicated. In the right-hand column, SETTING, a blank space is left so
that the user may note the value the relay has been set at.
TABLE 1 MLJ SETTINGS
SETTING NAME
RANGE STEP DEFAULT SETTING
GENERAL
0-1 Frequency 50/60 Hz N.A. 50 Hz
PROTECTION
1-1 Voltage difference 2-90 V 0.5 V 15 V
1-2 Angle 2-60º 1º 10º
1-3 Frequency slip 10-500
mHz
10 mHz 20 mHz
1-4 Continuous mode timing 0.1-99-0 s 0.1 s 0.1 s
1-5 Manual mode timing 0.1-99-0 s 0.1 s 10.1 s
2-1 Voltage supervision enable OFF-ON N.A. OFF
2-2 Voltage supervision threshold 10-180 V 1 V 40 V
3-1 Level present of voltage in line (V
L
↑
)
40-245 V 1 V 50 V
3-2 Level absent of voltage in line (V
L
↓
)
10-180 V 1 V 30 V
3-3 Level present of voltage in bus (V
B
↑
)
40-245 V 1 V 50 V
3-4 Level present of voltage in bus (V
B
↓
)
10-180 V 1 V 30 V
4-1 Synchronism unit enable OFF-ON N.A. OFF
4-2 (DLDB) dead line and bus enable OFF-ON N.A. OFF
4-3 (DLLB) dead line live bus enable OFF-ON N.A. OFF
4-4 (LLDB) live line dead bus enable OFF-ON N.A.. OFF
5-1 Configuration 1st auxiliary output see table 2 N.A. 25
5-2 Configuration 2nd auxiliary output see table 2 N.A. 27
COMMUNICATIONS
6-1 Unit number 1-255 1 1
6-2 Serial port baud-rate (kilobauds) 0.3-38.4 N.A. 9.6
