GE Multilin 745 User Manual

S6 Testing745
Transformer Management Relay
Setpoints
http://www.GEindustrial.com/multilin
5–96
GE Multilin
MESSAGE
W1 PHASE C CURRENT
MAGNITUDE: 1.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W1 PHASE C CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W1 GROUND CURRENT
MAGNITUDE: 0.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W1 GROUND CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W2 PHASE A CURRENT
MAGNITUDE: 1.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W2 PHASE A CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W2 PHASE B CURRENT
MAGNITUDE: 1.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W2 PHASE B CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W2 PHASE C CURRENT
MAGNITUDE: 1.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W2 PHASE C CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W2 GROUND CURRENT
MAGNITUDE: 0.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W2 GROUND CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W3 PHASE A CURRENT
MAGNITUDE: 1.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W3 PHASE A CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W3 PHASE B CURRENT
MAGNITUDE: 1.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W3 PHASE B CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W3 PHASE C CURRENT
MAGNITUDE: 1.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W3 PHASE C CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
W3 GROUND CURRENT
MAGNITUDE: 0.0 x CT
Range: 0.0 to 40.0 x CT in steps of 0.1
MESSAGE
W3 GROUND CURRENT
ANGLE: 0°
Range: 0 to 359° in steps of 1
MESSAGE
VOLTAGE INPUT
MAGNITUDE: 1.0 x VT
Range: 0.0 to 2.0 x VT in steps of 0.1
MESSAGE
VOLTAGE INPUT
ANGLE: 0° Lag
Range: 0 to 359° Lag in steps of 1
MESSAGE
FREQUENCY:
60.00 Hz
Range: 45.00 to 60.00 Hz in steps of
0.01
