Page #24 background imageLoading...
Page #24 background image
Overview
http://www.GEindustrial.com/multilin
2–8
GE Multilin
Specifications745
Transformer Management Relay
TYPE WITHSTAND TESTS
The following table lists the 745 type tests:
APPROVALS
ACA: Tick mark
RF Emissions for Australia
CE: Conforms to IEC 1010-1 / EN
50082-2
EN: EN 50623
EMC - CE for Europe
FCC: Part 15; RF Emissions for
North America
IEC: IEC 1010-1
LVD - CE for Europe
ISO: GE Multilin’s Quality
Management System is
registered to ISO9001:2000
QMI # 005094
UL #A3775
UL: UL listed for the USA and
Canada, E83849
It is recommended that all 745 relays be powered up at least once per year
to avoid deterioration of electrolytic capacitors in the power supply.
Specifications subject to change without notice.
Standard Test Name Level
GE Multilin Temperature Cycling –50°C to +80°C
IEC 60068-2-30 Relative Humidity Cyclic 55°C at 95% RH
IEC 60068-2-38 Composite Temperature/Humidity 65/–10°C at 93% RH
IEC 60255-5 Dielectric Strength 2300 V AC
IEC 60255-5 Impulse Voltage 5 kV
IEC 60255-21-1 Sinusoidal Vibration 2 g
IEC 60255-22-1 Damped Oscillatory Burst, 1 MHz 2.5 kV / 1 kV
IEC 60255-22-2 Electrostatic Discharge: Air and Direct 15 kV / 8 kV
IEC 60255-22-3 Radiated RF Immunity 10 V/m
IEC 60255-22-4 Electrical Fast Transient / Burst Immunity 4 kV
IEC 60255-22-5 Surge Immunity 4 kV / 2 kV
IEC 60255-22-6 Conducted RF Immunity, 150 kHz to 80 MHz 10 V/m
IEC 60255-25 Radiated RF Emission Group 1 Class A
IEC 60255-25 Conducted RF Emission Group 1 Class A
IEC 60529 Ingress of Solid Objects and Water (IP) IP40 (front), IP20 (back)
IEC 61000-4-8 Power Frequency Magnetic Field Immunity 30 A/m
IEC 61000-4-9 Pulse Magnetic Field Immunity 1000 A/m
IEC 61000-4-11 Voltage Dip; Voltage Interruption 0%, 40%, 100%
IEEE C37.90.1 Fast Transient SWC 4 kV / 4 kV
IEEE C37.90.1 Oscillatory Transient SWC 2.5 kV / 2.5 kV
NOTE
