GE VH UL series User Manual

Critical Power
Modifications reserved Page 7/25
GE_UPS_OPM_VHU_0K7_3K0_XUS_V011.docx Operating Manual VH700 UL, VH1000 UL, VH1500 UL, VH2000 UL & VH3000 UL
3 INSTALLATION
3.1 PACKAGE CONTENTS
The UPS shipping box contains:
 VH Series UPS
 4 plastic support parts
 Mounting set
 1 plastic front panel
 2 plastic plugs
 2 mounting brackets and screws
 1 input power cord (700-2000VA)
 1 USB cable
 1 CD ROM with UPS monitoring software (see
chapter 5) and its manual
 This manual
 REPO Connector (see 3.6.3 / 4.4.14)
Inspect the UPS for damage after unpacking. If any damage is present please immediately notify the carrier and place of
purchase.
WARNING! In case of recognizable damage:
DO NOT connect any voltage to the unit
DO NOT put the unit into operation
Condensation may occur if the UPS system is moved directly from a cold to a warm environment. The UPS system must
be absolutely dry before being installed. Please allow an acclimatization time of at least two hours prior to installation.
Save the original packing material. No liability can be accepted for any transport damage when the equipment is shipped
in non-original packaging.
3.2 INSTALLATION RULES
NOTE
Before making any connection and switching on the VH Series UPS, please check the following conditions:
 Your mains supply is 120 Volts and 50/60 Hz.
 The total power demand of the connected equipment does not exceed the rated output power of the VH Series UPS
(refer to chapter 8 for the ratings).
 The UPS is intended to be used in normal domestic and office situations.
 The UPS must be powered from a single phase grounded socket-outlet. Do not use extension cords.
VH3000: This socket-outlet shall be installed near the equipment and shall be easily accessible.
 Place cables in such a way that no one can step on or trip over them.
 Avoid locations that are excessively humid, near water, near heat sources or in direct sunlight.
 The ambient temperature should not exceed 104F (40C). Optimal battery lifetime is obtained if the ambient
temperature does not exceed 86F (30C).
 It is important that ventilation air can move freely around and through the unit. Do not block the air vents.
 Do not plug appliances such as electric heaters, toasters and vacuum cleaners into the UPS. The UPS output can be used
only for electronic loads such as computers and telecommunications equipment.
 Be careful when connecting laser printers: be sure that the demanded power does not exceed the capacity of the UPS.
 The sum of the leakage currents of the UPS and the connected loads should not exceed 3.5mA.
 Connect only to short circuit and over-current protection branch circuit rated in accordance with the National Electric
Code, ANSI/NFPA 70, see following table:
UPS model
Branch protection
UPS model
Branch protection
VH1500 UL
20A
VH700 UL
15A or 20A
VH2000 UL
20A
VH1000 UL
15A or 20A
VH3000 UL
30A
CAUTION
To reduce risk of fire, connect the UPS only to a circuit provided with fuse values according to the
above
