gefran 1600 User Manual

st.00
st.32
xead
pa.01
pa.14
led.1
led.2
led.3
LEd.x Function
0 none
1 MAN/AUTO (ON in manual, OFF in auto)
2 LOC/REM (ON in remote, OFF in local)
3 self-tuning enabled
4 autotuning enabled
5 IN1 repetition
6 IN2 repetition
7 enable serial dialogue
8 HOLD on
9 Error present (error code <> 0)
10 Softstart running
11 SP1...SP4 - bit Lo Indication
12 SP1...SP4 - bit Hi Indication
13 Start / Stop Timer
14 Reset Timer
Function of “MAN” LEDs: M/A, L/R, ATUN, IN1, IN2 repetition,
event programmer, serial port enabled, errors present
+ 16 for flashing LED function
LEd.1 (MAN), LEd.2 (AUX), LEd.3 (REM)
• Lin
Lin
Custom linearization for main
or aux input (*)
Step 0
Step 32
......
Scale Limits
Scale Limits
• CuSt
Set number of parameters
in custom menu
[ 0 ... 14 ]
CuSt
Set custom “dAtA” menu
Identification code for
parameter 1
Identification code for
parameter 14
......
• U.CAL
U.CAL
User
calibration
X X X X
x
The identification code is specified in this
position, under the parameter name
(*) Not available for :
enabled input correction function (SenS + 8)
TC custom input type (SenS = 0; tyPE = 20, 21)
RTD custom input type (SenS = 1; tyPE = 4, 5)
PTC custom input (SEnS = 2 ; tyPE = 2, 3)
U.CAL Function
1 Analogue output 1
2 Analogue output 2
3 Input 1 - custom probe 10V
4 Input 1 - custom probe 50mV
5 Input 2 - potentiometer
9
80080D_MHW_1600-1800_0308_ENG
