Page 7
4.3 PARAMETERISATION TELEGRAM (SAP 61)
The PROFIBUS Master uses this protocol before entering the “DATA EXCHANGE” operative state to identify itself
to the instrument and specify how it has to function. See the attached file 24000A40.gsd or 2500A40.gsd for
standard PROFIBUS parameterisations; the implementations introduced by byte 11 let the user define which
instrument variables to read and write in the Process data of that PROFIBUS node.
INSTRUMENTS
2400
2500
BYTE
DESCRIPTION
DEFAULT
HEX
DEFAULT
HEX
1≈7
In accordance with EN50170 - -
8≈10
Reserved 00 00
11 Process Data Input 1 (MSB) (530) PV1 LSW 02 (530) PV1 LSW 02
12 Process Data Input 1 (LSB) 12 12
13 Process Data Input 2 (MSB) (531) PV1 MSW 02 (531) PV1 MSW 02
14 Process Data Input 2 (LSB) 13 13
15 Process Data Input 3 (MSB) (536) Input 1 LSW 02 (532) Active SetPoint LSW 02
16 Process Data Input 3 (LSB) 18 14
17 Process Data Input 4 (MSB) (537) Input 1 MSW 02 (533) Active SetPoint MSW 02
18 Process Data Input 4 (LSB) 19 15
19 Process Data Input 5 (MSB) (538) Input 2 LSW 02 (534) Deviation SP-PV LSW 02
20 Process Data Input 5 (LSB) 1A 16
21 Process Data Input 6 (MSB) (539) Input 2 MSW 02 (535) Deviation SP-PV LSW 02
22 Process Data Input 6 (LSB) 1B 17
23 Process Data Input 7 (MSB) (540) Input 3 LSW 02 (536) Input 1 LSW 02
24 Process Data Input 7 (LSB) 1C 18
25 Process Data Input 8 (MSB) (541) Input 3 MSW 02 (537) Input 1 MSW 02
26 Process Data Input 8 (LSB) 1D 19
27 Process Data Input 9 (MSB) (542) Input 4 LSW 02 (538) Input 2 LSW 02
28 Process Data Input 9 (LSB) 1E 1A
29 Process Data Input 10 (MSB) (543) Input 4 MSW 02 (539) Input 2 MSW 02
30 Process Data Input 10 (LSB) 1F 1B
31 Process Data Input 11 (MSB) (544) Math funct. A LSW 02 (540) Input 3 LSW 02
32 Process Data Input 11 (LSB) 20 1C
33 Process Data Input 12 (MSB) (545) Math funct. A MSW 02 (541) Input 3 MSW 02
34 Process Data Input 12 (LSB) 21 1D
35 Process Data Input 13 (MSB) (546) Math funct. B LSW 02 (542) Input 4 LSW 02
36 Process Data Input 13 (LSB) 22 1E
37 Process Data Input 14 (MSB) (547) Math funct. B MSW 02 (543) Input 4 MSW 02
38 Process Data Input 14 (LSB) 23 1F
39 Process Data Input 15 (MSB) (1189) Controller status 04 (544) Math function A LSW 02
40 Process Data Input 15 (LSB) A5 20
41 Process Data Input 16 (MSB) (1192) Alarm status 04 (545) Math function A MSW 02
42 Process Data Input 16 (LSB) A8 21
43 Process Data Output 1 (MSB) (554) Alarm Point 1 LSW 02 (548) Local Setpoint LSW 02
44 Process Data Output 1 (LSB) 2A 24
45 Process Data Output 2 (MSB) (555) Alarm Point 1 MSW 02 (549) Local Setpoint MSW 02
46 Process Data Output 2 (LSB) 2B 25
47 Process Data Output 3 (MSB) (556) Alarm Point 2 LSW 02 (550) Setpoint 1 LSW 02
48 Process Data Output 3 (LSB) 2C 26
49 Process Data Output 4 (MSB) (557) Alarm Point 2 MSW 02 (551) Setpoint 1 MSW 02
50 Process Data Output 4 (LSB) 2D 27
51 Process Data Output 5 (MSB) (558) Alarm Point 3 LSW 02 (552) Setpoint 2 LSW 02
52 Process Data Output 5 (LSB) 2E 28
53 Process Data Output 6 (MSB) (559) Alarm Point 3 MSW 02 (553) Setpoint 2 MSW 02
54 Process Data Output 6 (LSB) 2F 29
55 Process Data Output 7 (MSB) (560) Alarm Point 4 LSW 02 (554) Alarm Point 1 LSW 02
56 Process Data Output 7 (LSB) 30 2A
57 Process Data Output 8 (MSB) (561) Alarm Point 4 MSW 02 (555) Alarm Point 1 MSW 02
58 Process Data Output 8 (LSB) 31 2B
