Chapter 6 Accessories
6.1 Input choke Specifications
Model
Specification
Choke
Model
Code
Dimensions
Weight
Current
(A)
Inductance
(mH)
(1)
WxHxd (mm) (kg)
BDI50-1004-…-2M
7.2
3.05
BDI50-1007…-2M
11.0
2.00
BDI50-2015…-2M
15.5
1.42
BDI50-2022-…-2M
21.0
1.05
BDI50-1007-…-2T
11.0
2.00
LR3y-1030
S7AB3
120 x 125 x 65
1.9
BDI50-2015-…-2T
15.5
1.42
LR3y-2040
S7AAG
120 x 125 x 65
2
BDI50-2022-…-2T
21.0
1.05
LR3y-2055
S7AB5
120 x 125 x 75
2.2
BDI50-3037-…-2T
20.0
0.63
LR3y-2075
S7AB6
150 x 155 x 79
4.9
BDI50-4055-…-2T
33.0
0.38
LR3y-3110
S7AB7
150 x 155 x 79
5
BDI50-4075-…-2T
42.0
0.30
LR3y-3150
S7AB8
150 x 169 x 85
5.5
BDI50-2007-…-4
4.2
5.25
LR3y-1007
S7AAD
120 x 125 x 65
1.8
BDI50-2015-…-4
5.6
3.94
LR3y-1015
S7AAE
120 x 125 x 65
1.8
BDI50-2022-…-4
7.3
3.02
LR3y-1022
S7AAF
120 x 125 x 65
1.8
BDI50-3037-…-4
12.0
1.84
LR3y-2040
S7AAG
120 x 125 x 65
2
BDI50-3055-…-4
17.0
1.30
LR3y-2055
S7AB5
120 x 125 x 75
2.2
BDI50-4075-…-4
23.0
0.96
LR3y-2075
S7AB6
150 x 155 x 79
4.9
BDI50-4110-…-4
31.0
0.71
LR3y-3110
S7AB7
150 x 155 x 79
5
※Note: (1) Calculated inductance based on 3% reactance.
6.2 Output choke Specifications
Model
Choke Model Code
Dimensions
Weight
WxHxd (mm)
(kg)
BDI50-1004-…-2M
LU3-001
S7FG1
120 x128 x 71
2.7
BDI50-1007…-2M
LU3-001
S7FG1
120 x128 x 71
2.7
BDI50-2015…-2M
LU3-003
S7FG2
180 x 170 x 110
5.2
BDI50-2022-…-2M
LU3-005
S7FG3
180 x 170 x 110
5.8
BDI50-1007-…-2T
LU3-001
S7FG1
120 x128 x 71
2.7
BDI50-2015-…-2T
LU3-003
S7FG2
180 x 170 x 110
5.2
BDI50-2022-…-2T
LU3-005
S7FG3
180 x 170 x 110
5.8
BDI50-3037-…-2T
LU3-011
S7FG4
180 x 180 x 130
8
BDI50-4055-…-2T
LU3-011
S7FG4
180 x 180 x 130
8
BDI50-4075-…-2T
LU3-015
S7FH2
180 x 160 x 170
7.5
BDI50-2007-…-4
LU3-001
S7FG1
120 x128 x 71
2.7
BDI50-2015-…-4
LU3-001
S7FG1
120 x128 x 71
2.7
BDI50-2022-…-4
LU3-001
S7FG1
120 x128 x 71
2.7
BDI50-3037-…-4
LU3-003
S7FG2
180 x 170 x 110
5.2
BDI50-3055-…-4
LU3-005
S7FG3
180 x 170 x 110
5.8
