gefran BDI50-3037-KBX-4-NP-F User Manual

3-28
3.5.5 Three phase (NPN / PNP Selectable models)
400V: BDI50-3037-...-4-NP ... BDI50-4110-...-4-NP
230V: BDI50-3037-...-2T-NP ... BDI50-4075-...-2T-NP
(
MCCB
L1
AC
source
S2
S3
S4
AO
3
+
250VAC/1A
(30VDC/1A)
T1
T2
T3
RB
RA
S5
L3
(
ON-OFF
Surge
Suppressor
10V
AVI
ACI
GND
Magnetic
Contactor
RS485
FWD (Run/Stop)
REV (Run/Stop)
Speed Control
External speed
potentiometer = 10 Kohm
or PID input
Induction
Motor
COM:NPN
MC
Thermal
relay
MC
S1
GND
0~10V
2
AO
+
-
Frequency
Indicator
0~10VDC
CON2
Thermal
relay
M
0~20mA
P
P'
2'
1
-
L2
(
+24V:NPN *
RC
SC
COM:PNP
+24V:PNP
Power
input
P
BR
Inverter
output
Ground
Pin 1 to Pin 8
Multifunction
Input
Terminals
Relay
Output
Analog
Output
Analog
Input
NPN/PNP input type selection
PNP: 1.Link SC and COM terminal
2.Use +24v terminal for S1~S5 common point
NPN: 1.Link SC and +24V terminal
2.Use COM terminal for S1~S5 common point
Please ensure correct connection before setting parameter group 3 digital inputs.
