gefran BDI50-3037-KBX-4-NP-F User Manual

6-2
Model
Choke Model
Code
Dimensions
Weight
BDI50-4075-…-4
LU3-011
S7FG4
180 x 180 x 130
8
BDI50-4110-…-4
LU3-011
S7FG4
180 x 180 x 130
8
※Note: Chokes for inverter max frequency = 400 Hz and max Switching frequency = 20 kHz.
6.3 Fuse Specification
Model
HP
kW
Rating (aR type)
BDI50-1004-…-2M / 2T
0.5
0.4
15A / 300VAC
BDI50-1007-…-2M / 2T
1
0.75
15A / 300VAC
BDI50-2015-…-2M / 2T
2
1.5
30A / 300VAC
BDI50-2022-…-2M / 2T
3
2.2
30A / 300VAC
BDI50-3037-…-2T
5
3.7
30A / 300VAC
BDI50-4055-…-2T
7.5
5.5
60A / 300VAC
BDI50-4075-…-2T
10
7.5
60A / 300VAC
BDI50-2007-…-4
1
0.75
5A / 600VAC
BDI50-2015-…-4
2
1.5
15A / 600VAC
BDI50-2022-…-4
3
2.2
20A / 600VAC
BDI50-3037-…-4
5
3.7
20A / 600VAC
BDI50-3055-…-4
7.5
5.5
40A / 600VAC
BDI50-4075-…-4
10
7.5
40A / 600VAC
BDI50-4110-…-4
15
11
70A / 600VAC
6.4 Fuse Specification (UL Model Recommended)
Model
Manufacture
Type
Rating
BDI50-1004-…-2M
Bussmann
10CT/16CT
690V 10A/690V 16A
BDI50-1007-…-2M
Bussmann
16CT/20CT
690V 16A/690V 20A
BDI50-2015-…-2M
Bussmann
30FE
690V 30A
BDI50-2022-…-2M
Bussmann
50FE
690V 50A
BDI50-1007-…-2T
Bussmann
10CT
690V 10A
BDI50-2015-…-2T
Bussmann
16CT
690V 16A
BDI50-2022-…-2T
Bussmann
20CT
690V 20A
BDI50-3037-…-2T
Bussmann
50FE
690V 50V
BDI50-4055-…-2T
Bussmann
63/100 FE
690V 63A
BDI50-4075-…-2T
Bussmann
80/100 FE
690V 80/690V100A
BDI50-2007-…-4
Bussmann
10CT
690V 10A
BDI50-2015-…-4
Bussmann
16CT
690V 16A
BDI50-2022-…-4
Bussmann
20CT
690V 20A
BDI50-3037-…-4
Bussmann
25ET
690V 25A
BDI50-3055-…-4
Bussmann
40FE
690V 40A
BDI50-4075-…-4
Bussmann
50ET
690V 50A
BDI50-4110-…-4
Bussmann
63ET
690V 63A
