50960066/AP0813 44 PRINTED IN U.S.A.
GREASING
Refer to the illustrations and listings for fitting loca-
tions. Wipe dirt from the fittings before greasing them
to prevent contamination. Replace any missing or dam-
aged fittings. To minimize dirt build-up, avoid exces-
sive greasing.
BASIC MACHINE GREASE FITTING
LOCATIONS
Every 50 Hours (or weekly)
Refer to the illustration on the facing page for loca-
tions.
CHASSIS AREA
1 Wheel spindle pins (per axle) . . . . . . . . . . . .4
2 Axle pivot pins (rear axle) . . . . . . . . . . . . . .2
3 Drive shaft, u-joint . . . . . . . . . . . . . . . . . . . .2
4 Drive shaft, slip joint (front axle) . . . . . . . . .1
5 Base end lift cylinder pivot pin . . . . . . . . . .1
6 Base end slave cylinder pivot pin . . . . . . . .1
BOOM AREA
7 Boom to frame upright pivot pin . . . . . . . . .2
8 Rod end slave cylinder pivot pin . . . . . . . . .1
9 Rod end lift cylinder pin . . . . . . . . . . . . . . .1
10 Extend cylinder pivot pins . . . . . . . . . . . . . .3
11 Quick-attach to boom nose pivot pins . . . . .2
12 Tilt cylinder pivot pins . . . . . . . . . . . . . . . . .2
13 Boom slide pads - as required, front and rear
FILTER REFERENCE CHART
TYPE PART NUMBER
Engine Oil Filter 195568
Engine Fuel Filter 50352551
Water Separator Filter 50352550
Air Filter Primary 104047
Secondary 104046
Hydraulic Return Filter 074830
Cab Ventilation Filter 211146
IMPORTANT
To ensure continued proper operation, use
only genuine Gehl replacement filters.
