ENGINE DIAGNOSTIC TROUBLE CODES (DTCs)
Engine diagnostic trouble codes are displayed in the
multi-function display screen.
Diagnostic trouble codes are displayed as a two-part
code: Suspect Parameter Number (SPN) and Failure
Mode Identifier (FMI), as shown on the following
table.
The first part is a Suspect Parameter Number (SPN)
followed by a Failure Mode Identifier (FMI). To deter-
mine the exact type of failure, both parts (SPN and
FMI) of the code are needed.
The SPN identifies the system or the component that
has the failure; for example, SPN 000110 indicates a
failure in the engine coolant temperature sensor.
The FMI identifies the type of failure that has
occurred; for example, FMI 03 indicates a value above
normal. Combining SPN 000110 with FMI 03 means
the engine coolant temperature input voltage is too
high. This example would display in the multi-function
display as error code 000110-03.
Always contact your servicing engine dealer for help
in correcting the diagnostic trouble codes that are dis-
played for the engine.
The fault code listing in the following tables are in
ascending SPN/FMI codes.
DTC
SPN FMI Error Code Type
000029 00 Accelerator Pedal Position Sensor “B”
01 Accelerator Pedal Position Sensor “B”
02 Accelerator Pedal Position Sensor “B”
03 Accelerator Pedal Position Sensor “B”
04 Accelerator Pedal Position Sensor “B”
08 Accelerator Pedal Position Sensor “B”
15 Accelerator Pedal Position Sensor “B”
000091 00 Accelerator Pedal Position Sensor “A”
01 Accelerator Pedal Position Sensor “A”
02 Accelerator Pedal Position Sensor “A”
03 Accelerator Pedal Position Sensor “A”
04 Accelerator Pedal Position Sensor “A”
15 Accelerator Pedal Position Sensor “A”
000100 01 Oil Pressure
04 Oil Pressure Switch
000108 02 Barometric Pressure Sensor
03 Barometric Pressure Sensor
04 Barometric Pressure Sensor
000110 00 Engine Coolant Temperature
02 Engine Coolant Temperature Sensor
03 Engine Coolant Temperature Sensor
04 Engine Coolant Temperature Sensor
000158 00 System Voltage
01 System Voltage
000167 01 Charge Warning
04 Battery Charge Switch
000190 00 Engine Speed
000628 02 E-ECU Internal Fault
02 E-ECU Internal Fault
12 E-ECU Internal Fault
000630 02 E-ECU Internal Fault
12 E-ECU Internal Fault
Error Description
Above normal operational range
Below normal operational range
Intermittent fault
Shorted to high source
Shorted to low source
Communication fault
Not available
Above normal operational range
Below normal operational range
Intermittent fault
Shorted to high source
Shorted to low source
Not available
Too Low
Shorted to low source
Intermittent fault
Shorted to high source
Shorted to low source
Too high
Intermittent fault
Shorted to high source
Shorted to low source
Too high
Too low
Shorted to low source
Over speed condition
FlashROM Check Sum Error (Data Set 1)
FlashROM Check Sum Error (Data Set 2)
FlashROM Check Sum Error (Main Software)
EEPROM Check Sum Error (Data Set 2)
EEPROM Read / Write fault
