5 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Order codes
1 Type Code
Pilot valve 8500
2 Way version Code
3/2-way 32
5/2-way 52
3 NAMUR Code
Standard
Flex plate F
NAMUR N
4 DN Code
DN 7 7
5 Body configuration Code
Multi-port version M
6 Connection type Code
Thread G1/4" G2
7 Valve body material Code
AA-2015,
AlCuMgSn
14
8 Seal material Code
NBR 2
9 Control function Code
Combined spring return 1
Pneumatic spring (ATEX) A
10 Voltage/frequency Code
12 V DC B1
24 V DC C1
24 V/50 - 60 Hz C4
48 V DC D1
110 V/50 - 60 Hz E4
230 V/50 - 60 Hz L4
11 Special version Code
Without
180° rotation R
12 Special version Code
Without
UL approval U
ATEX version X
Order example
Order option Code Description
1 Type 8500 Pilot valve
2 Way version 32 3/2-way
3 NAMUR N NAMUR
4 DN 7 DN 7
5 Body configuration M Multi-port version
6 Connection type G2 Thread G1/4"
7 Valve body material 14 AA-2015,
AlCuMgSn
8 Seal material 2 NBR
9 Control function 1 Combined spring return
10 Voltage/frequency C1 24 V DC
11 Special version Without
12 Special version Without
5 Order data
www.gemu-group.com 7 / 24 GEMÜ 8500
