6 Technical data
6.1 Medium
Working medium: Filtered, lubricated or unlubricated compressed air which has no negative impact on the physical
and chemical properties of the valve body and seal material.
Air quality acc. to ISO 8573-1:2010:7-4-4 for particles, water and oil
6.2 Temperature
Media temperature: AC operation: -10 to 50 °C
DC operation: -10 to 60 °C
6.3 Pressure
Operating pressure: 2,5 to 10 bar
Flow rate: 1250 Nl/min
6.4 Product compliance
Machinery Directive: 2006/42/EC
EMC Directive: 2014/30/EU
Explosion protection: Special version X order code
ATEX marking: Gas: II 2G Ex mb IIC T4/T5 Gb
Dust: II 2D Ex mb tb IIIC T95°C, T130°C Db
6.5 Mechanical data
Protection class: IP 65
Installation position: Optional
Weight: 3/2-way standard:
5/2-way standard:
0.21 kg
0.25 kg
3/2-way and 5/2-way
NAMUR:
0.26 kg
6.6 Electrical data
Power consumption: AC operation: 5 VA
DC operation: 3 W
Switching times: 20 ms ± 4 ms
Permissible voltage toler-
ance:
±10 % to VDE 0580
Duty cycle: Continuous duty
Wiring note: Special wiring on request. When using electronic switches and additional wiring, carefully design
out any potential residual currents upon installation.
Electrical connection
type:
Plug, design B
www.gemu-group.com8 / 24GEMÜ 8500
6 Technical data
