SECTION 9: ENGINE DISASSEMBLY
SECTION CONTENTS
PAGE
ENGINE
DTSASSEMBLY ..................................................
9-1
ENGINE
DISASSEMBLY
Drdrn oil, re'nove oil
'ilte'
and
rerove engine f'om equ'p-
ment.
Remove spark
plugs.
Remove flywheel, disconnect
stop
switch
wires at armatures and remove armatures
(see
Section
2). Remove cylinder
heads
(see
Seclion 5).
1. Remove the following
parts
(Figure
9'1):
a.
Brcather Assembly b. Alternator
c, Backplate
d. Starter Motor
2. Remove ctankcase cover
a. Discard
gasket
and O-ring.
3. Rotate c€nkshaft
and
camshaft
untilliming marks allgn
and remove camshaft
(Figure
9-2).
Note: lf
necessary,
place
the engine
flWheel side down
to
pfevent
tappets ffom catching on
the camshaft
a.
Remove tappets.
Figwe 9'1
. Remove Alternatot
Backplate, S|d,raer Motor
..1:
,'
@ob
Figwe 9-2.
9-1
