Technical specifications
Optical specifications
3
Lucea 50_100
01740 EN 01
9 / 44
3 Technical specifications
3.1 Optical specifications
Specifications LUCEA 50 LUCEA 100 Tolerance
Nominal illumination 60,000lx 120,000lx ± 10 %
Diameter d10 22 cm ± 3 cm
Diameter d50/d10 0.55 ± 0.05
Illumination depth at 20% 190 cm 105 cm ± 15 %
Illumination depth at 60% 120 cm 55 cm ± 15 %
Colour temperature 4,300 K ± 450 K
Colour rendering index (Ra) 96 ± 4
Special colour rendering index (R9) 92 ± 10
Irradiance (Ee) < 250 W/m² < 500 W/m²
Radiant energy 3.9 mW/m²/lx ± 0.4
UV illumination ≤ 0.7 W/m²
FSP system Yes
Tab.3: Table of LUCEA 50-100 optical data
Specifications LUCEA 50 LUCEA 100 Tolerance
With one mask 5 % 42 % ±10
With two masks 58 % 49 % ±10
At base of tube 100 % 96 % ±10
With one mask, at base of tube 5 % 38 % ±10
With two masks, at base of tube 58 % 46 % ±10
Tab.4: LUCEA 50-100 residual illumination
NOTE
These values are measured with the small light field diameter.
