Gigabyte GA-6VXE7+ User Manual

Table of Contents
1
TABLE OF CONTENTS
1. INTRODUCTION
1.1. PREFACE ................................................................................................ 1-1
1.2. KEY FEATHERS ...................................................................................... 1-1
1.3. PERFORMANCE LIST ............................................................................. 1-2
1.4. BLOCK DIAGRAM.................................................................................... 1-3
1.5. INTRODUCE THE INTEL

Celeron
TM
Socket 370 Processor................... 1-4
1.6. WHAT IS AGP?........................................................................................ 1-4
2. SPECIFICATION
2.1. HARDWARE ............................................................................................ 2-1
2.2. SOFTWARE............................................................................................. 2-2
2.3. ENVIRONMENT....................................................................................... 2-2
3. HARDWARE INSTALLATION
3.1. UNPACKING............................................................................................ 3-1
3.2. MOTHERBOARD LAYOUT ...................................................................... 3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS........................ 3-2
3.4. DRAM INSTALLATION............................................................................. 3-6
3.5. CPU SPEED SETUP................................................................................ 3-6
3.6. CMOS RTC & ISA CFG CMOS RAM........................................................ 3-7
3.7. SPEAKER CONNECTOR INSTALLATION............................................... 3-8
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION ............... 3-8
3.9. POWER LED CONNECTOR INSTALLATION .......................................... 3-8
3.10. IDE & ATAPI DEVICE INSTALLATION................................................... 3-8

Gigabyte GA-6VXE7+ Specifications

General

ECC	Yes
Memory voltage	3.3 V
Number of memory slots	3
Maximum internal memory	1.5 GB
Processor socket	Socket 370
Processor manufacturer	Intel
Number of COM connectors	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Motherboard chipset	-
Motherboard form factor	ATX
Compatible operating systems	Windows 95/98/2000/ME
PCI slots	5

Weight and Dimensions

Depth	200 mm
Width	305 mm
