Hardware Installation
3-1
3. HARDWARE INSTALLATION
3.1. UNPACKING
The Motherboard package should contain the following:
•
The
6VXE7+
Motherboard.
•
USER’S MANUAL for Motherboard.
•
Cable set for IDE, Floppy devices.
•
A CD for Motherboard Utility.(TUCD)
The motherboard contains sensitive electric components, which can be easily
damaged by static electricity, so the Motherboard should be left in its original
packing until it is installed.
Unpacking and installation should be done on a grounded anti-static mat. The
operator should be wearing an anti static wristband, grounded at the same point
as the anti-static mat.
Inspect the Motherboard carton for obvious damage. Shipping and handling
may cause damage to your board. Be sure there are no shipping and handling
damages on the board before proceeding.
After opening the Motherboard carton, extract the system board and place it
only on a grounded anti-static surface component side up. Again inspect the
board for damage. Press down on all of the socket IC's to make sure that they
are properly seated. Do this only on with the board placed on a firm flat surface.
0
00
0
DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN DAMAGED.

Gigabyte GA-6VXE7+ Specifications

General

ECC	Yes
Memory voltage	3.3 V
Number of memory slots	3
Maximum internal memory	1.5 GB
Processor socket	Socket 370
Processor manufacturer	Intel
Number of COM connectors	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Motherboard chipset	-
Motherboard form factor	ATX
Compatible operating systems	Windows 95/98/2000/ME
PCI slots	5

Weight and Dimensions

Depth	200 mm
Width	305 mm
