Gigabyte GA-6VXE7+ User Manual

6VXE7+
1-4
1.5. INTRODUCE THE INTEL



Pentium



!!!
Socket 370 Processor
Figure 1: INTEL

Pentium

!!!
Socket 370 Processor(FC-PGA)
Figure 2: INTEL

Pentium

!!!
Socket 370 Processor(PPGA)
1.6 What is AGP
?
??
?
The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge
device that supports an AGP port. The main purpose of the AGP port is to
provide fast access to system memory.
The AGP port can be used either as fast PCI port (32-bits at 66MHz vs.32-Bits
at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and
side band addressing. When the 2x-data rate is used the port can transmit data
at 533MB/sec (66.6*2*4). The read-queue can be used to pipeline reads –
removing the effects of the reads-latency. Side band addressing can be used
to transmit the data address on a separate line in order to speed up the
transaction.

Gigabyte GA-6VXE7+ Specifications

General

ECC	Yes
Memory voltage	3.3 V
Number of memory slots	3
Maximum internal memory	1.5 GB
Processor socket	Socket 370
Processor manufacturer	Intel
Number of COM connectors	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Motherboard chipset	-
Motherboard form factor	ATX
Compatible operating systems	Windows 95/98/2000/ME
PCI slots	5

Weight and Dimensions

Depth	200 mm
Width	305 mm
