Gigabyte GA-EP43-UD3L User Manual

GA-EP43-UD3L/US3L Motherboard - 10 -
1-2 Product Specifications
CPU  Support for an Intel
®
Core
TM
2 Extreme processor/
Intel
®
Core
TM
2 Quad processor/Intel
®
Core
TM
2 Duo processor/
Intel
®
Pentium
®
Dual-Core processor/Intel
®
Celeron
®
processor
in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)
 L2 cache varies with CPU
Front Side Bus  1600(O.C.)/1333/1066/800 MHz FSB
Chipset  North Bridge: Intel
®
P43 Express Chipset
 South Bridge: Intel
®
ICH10
Memory  4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
 Dual channel memory architecture
 Support for DDR2 1200/1066/800/667 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio  Realtek ALC888 codec
 High Definition Audio
 2/4/5.1/7.1-channel
 Support for S/PDIF In/Out
 Support for CD In
LAN  1 x Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
 4 x PCI Express x1 slots
 2 x PCI slots
Storage Interface  South Bridge:
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
 JMicron 368 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
 iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB  Integrated in the South Bridge
 Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
"*" The GA-EP43-UD3L adopts All-Solid Capacitor design.

Gigabyte GA-EP43-UD3L Specifications

General

Memory voltage	1.8 V
Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	2
Power fan connector	Yes
Number of SATA connectors	6
Number of EATX power connectors	1
Special features	@BIOS Q-Flash Virtual Dual BIOS Download Center Xpress Install Xpress Recovery2 EasyTune Dynamic Energy Saver Advanced Time Repair Q-Share
Controller interface type	iTE IT8718
USB 2.0 ports quantity	8
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC888
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 9X/ME/Vista/XP
LAN controller	Realtek RTL8111C
Networking features	10/100/1000 Mbit
