Use the differential lock only with creep and normal speed ranges

and reduce engine Rpm well ahead. Do not use the differential

going into or in curves. If the differential lock does not release, reduce

engine revs, stop tractor forward movement and release the differential by

moving the steering wheel.

4.7 REAR PTO

See fig. 1

Use lever 20 (disengaged forward; engaged back)

Engage the PTO using:

lever n.13 for models 20 - 26 - 30 - 746 - 846 - 946

lever n.32 for models 35 - 37 - 40 – 1046 – 1047 - 1247

set the lever on 540 or 1000/2000 Rpm.

Engage the clutch by lowering lever n.20.

The PTO can be disengaged for short periods using only lever 20 without

bothering with lever n.13 for models 20 - 26 - 30 - 746 - 846 - 946 and lever n.32

for models 35 - 37 - 40 – 1046 – 1047 – 1247.

Form: 1" 3/8 ASAE 6 splines

Speed: 540 Rpm with engine at 2607 Rpm

Speed: 1000 Rpm with engine at 2615 Rpm

Speed: 2000 Rpm with engine at 2947 Rpm optional (as an alternative to 1000

Rpm).

Rotation direction: clockwise

Synchronized PTO: (lever n.17 fig.1)

Form 1" 1/8 ASAE with 6 splines

Ratio: 20.51 PTO revolutions per wheel revolution).

Anticlockwise turning direction with forward gears.

4.7.1 Mid PTO

(Optional)

See fig. 1

Use lever 20 (disengaged forward: engaged when back)

Engage the PTO with lever n.15 position 1.

Engage the clutch by pulling lever n.20 back.

The PTO can be disengaged for short periods using only lever 20 without

bothering with lever n.15.

Form: 1" 1/8 ASAE with 6 splines

Turning direction: anticlockwise

Speed: 1000 Rpm with engine at 2525 Rpm (this PTO is combined with the

540/1000 Rpm rear PTO).

Speed: 2000 Rpm with engine at 2947 Rpm (this PTO is combined with the
