Goodwe EH Plus Series Manual

2.1 UNACCEPTABLE INSTALLATIONS
2.2 PACKING LIST
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
05 06
Smart Meter
2.3.1 SELECT MOUNTING LOCATION
2.3 MOUNTING
Direct Sunlight Exposure to Rain Exposure to SnowNo Direct Sunlight No Exposure to Rain No Exposure to Snow
Pic 2
Upward----------
Downward------
Front-------------
Both sides-------
300mm
500mm
300mm
200mm
300mm
300mm
200mm
200mm
500mm
Pic 3
Pic 1
INSTALLATION INSTRUCTIONS02
PE terminal × 1 Expansion bolts×4
User manual×1
Quick Installation
Guide×1
Smart Meter
& CT × 1
Inverter×1
Wall-mounted
Bracket×1
15°
Back Up AC Plug X1 On Grid AC Plug X1
INVERTER BATTERY CANNOT CONNECT TO
INCOMPATIBLE BATTERIES.
Any part of this system shouldn’t block the switch and breaker to disconnected inverter from
DC and AC power.
On receiving the hybrid inverter, please check to make sure all the components as below
are not missing or broken. Of course, there are no Smart Meter and Smart Meter User
Manual if you buy a Battery-Ready inverter without the Smart Meter.
For inverter’s protection and convenient maintenance, mounting location for inverter
should be selected carefully based on the following rules:
Rule 1. Inverter should be installed on a solid surface, where is suitable for inverter’s
dimensions and weight.
Rule 2. Inverter installation should stand vertically or lie on a slop by max 15° (Pic 1)
Rule 3.
Ambient temperature should be lower than 45 ℃
Rule 4. The installation of inverter should be protected under shelter from direct sunlight or bad
weather like snow, rain, lightning etc. (Pic 2)
Rule 5. Inverter should be installed at eye level for convenient maintenance.
Rule 6. Product label on inverter should be clearly visible after installation.
Rule 7. Leave enough space around inverter following the values on pic 3.
Inverter cannot be installed near flammable, explosive or strong electro-magnetic equip-
ment.
[1]
ON-GRID OR BACK-UP SIDE CANNOT
CONNECT TO ANY AC GENERATOR.
Incompatible
battery
Positive PV
Plug×2
Negative PV
Plug×2
Positive BAT
Plug×1
Negative BAT
Plug×1
Back-Up
Back-Up
Load
BACK-UP CANNOT CONNECT IN PARALLEL.
SINGLE PV STRING CANNOT CONNECT TO TWO OR
MORE INVERTERS.
ONE METER CANNOT CONNECT TO MULTI INVERTERS, AND
DIFFERENT CT CANNOT CONNECT TO A SAME FIER CABLE.
ONE BATTERY BANK CANNOT BE CONNECTED TO
MULTI INVERTERS.
BACK-UP SIDE CANNOT
CONNECT TO GRID
PV PV
