5.2 Inverter Installation
5.2.1 Moving the Inverter
CAUTION
Move the inverter to the site before installation. Follow the instructions below to avoid personal
injury or equipment damage.
1. Consider the weight of the equipment before moving it. Assign enough personnel to move
the equipment to avoid personal injury.
2. Wear safety gloves to avoid personal injury.
3. Keep balance when moving the equipment.
5.2.2 Installing the Inverter
NOTICE
• Avoid the water pipes and cables buried in the wall when drilling holes.
• Wear goggles and a dust mask to prevent the dust from being inhaled or contacting eyes
when drilling holes.
• The anti-theft lock of appropriate size should be prepared by customers. Diameter of the
lock hole is 10mm.
• Make sure that all the DC input terminals are inside the PV box when installing the box.
Install the box cling to the bottom of the inverter.
Step 1 Put the mounting plate on the wall horizontally and mark positions for drilling holes.
Step 2 Drill holes to a depth of 80mm using the hammer drill. The diameter of the drill bit should
be 10mm.
Step 3 Secure the mounting plate using the expansion bolts.
Step 4 Install the inverter on the mounting plate.
Step 5 Tighten the nuts to secure the mounting plate and the inverter.
Step 6 Install the anti-theft lock.
Step 7 (For Australia and New Zealand) Install the PV box and the PV box mounting plate
together using the delivered M5 screws.
Step 8 (For Australia and New Zealand) Drill holes to a depth of 60mm using the hammer drill.
The diameter of the drill bit should be 8mm.
Step 9 (For Australia and New Zealand) Secure the PV box at the bottom of the inverter using the
delivered expansion bolts.
