Startup
Startup Startup
Startup
Topreventseriousinjury,onlyoperateReactorwith
allcoversandshroudsinplace.
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensuresteady
voltage.Failuretofollowtheseprocedureswill
causevoltage󰘱uctuationsthatcandamage
electricalequipmentandvoidthewarranty.
1.Check󰘱uidinlet󰘰lterscreens.
Beforedailystartup,ensurethatthe
󰘱uidinletscreensareclean.See
FluidInletStrainerScreens,page64.
2.CheckISOlubricationreservoir.
ChecklevelandconditionofISOlubedaily.See
PumpLubricationSystem,page66.
3.UseAandBDrumLevelSticks(24M174)to
measurethemateriallevelineachdrum.If
needed,thelevelcanbeenteredandtrackedin
theADM.SeeAdvancedSetupScreens,page37.
4.Checkgeneratorfuellevel.
NOTICE NOTICE
NOTICE
Runningoutoffuelwillcausevoltage
󰘱uctuationsthatcandamageelectrical
equipmentandvoidthewarranty.Donotrun
outoffuel.
5.Con󰘰rmmainpowerswitchisOFFbeforestarting
generator.
6.Ensurethemainbreakeronthegeneratorisin
theoffposition.
7.Startthegenerator.Allowittoreachfulloperating
temperature.
8.Turn Turn
Turn
main main
main
power power
power
switch switch
switch
ON. ON.
ON.
TheADMwilldisplaythefollowingscreenuntil
communicationandinitializationiscomplete.
334945J
47
