Maintenance
Maintenance Maintenance
Maintenance
Priortoperforminganymaintenanceprocedures,
followPressureReliefProcedure,page62.
Preventative Preventative
Preventative
Maintenance Maintenance
Maintenance
Schedule Schedule
Schedule
Theoperatingconditionsofyourparticularsystem
determinehowoftenmaintenanceisrequired.
Establishapreventivemaintenancescheduleby
recordingwhenandwhatkindofmaintenanceis
needed,andthendeterminearegularschedulefor
checkingyoursystem.
•Inspecthydraulicand󰘱uidlinesforleaksdaily.
•Cleanupallhydraulicleaks;identifyandrepairthe
causeoftheleak.
•Inspect󰘱uidinletstrainerscreensdaily.Seebelow.
•KeepcomponentAfromexposuretomoistureto
preventcrystallization.
•Checkhydraulic󰘱uidlevelweekly.Check
hydraulic󰘱uidlevelonadipstick.Fluidlevel
mustbebetweenindentmarksondipstick.
Re󰘰llasrequiredwithapprovedhydraulic󰘱uid,
seeTechnical Technical
Technical
Speci󰘰cations Speci󰘰cations
Speci󰘰cations
andtheApproved
Anti-Wear(AW)HydraulicOilstableintheReactor
Repair-Partsmanual334946.If󰘱uidisdarkin
color,change󰘱uidand󰘰lter.
•Changebreak-inoilinanewunitafterthe󰘰rst250
hoursofoperationorwithin3months,whichever
comes󰘰rst.Seethetablebelowforrecommended
frequencyofoilchanges.
Table Table
Table
5 5
5
Frequency Frequency
Frequency
of of
of
Oil Oil
Oil
Changes Changes
Changes
Ambient Ambient
Ambient
Temperature Temperature
Temperature
Recommended Recommended
Recommended
Frequency Frequency
Frequency
0°to90°F
(-17°to32°C)
1000hoursor12months,
whichevercomes󰘰rst
90°Fandabove
(32°Candabove)
500hoursor6months,
whichevercomes󰘰rst
Proportioner Proportioner
Proportioner
Maintenance Maintenance
Maintenance
Fluid Fluid
Fluid
Inlet Inlet
Inlet
Strainer Strainer
Strainer
Screens Screens
Screens
Inspect󰘱uidinletstrainerscreensdaily,see
FluidInletStrainerScreens,page64.
Grease Grease
Grease
Circulation Circulation
Circulation
Valves Valves
Valves
Greasecirculationvalves(SAandSB)withFusion
grease(117773)weekly.
ISO ISO
ISO
Lubricant Lubricant
Lubricant
Level Level
Level
InspectISOlubricantlevelandcondition
daily.Re󰘰llorreplaceasneeded.See
PumpLubricationSystem,page66.
Moisture Moisture
Moisture
Topreventcrystallization,donotexposecomponent
Atomoistureinair.
Gun Gun
Gun
Mix Mix
Mix
Chamber Chamber
Chamber
Ports Ports
Ports
Cleangunmixchamberportsregularly.Seegun
manual.
64 334945J
